    OMRON AC Servomotor With ABS INC Encoder 50W 100 VAC R88M-G05030T Without Key Without Brake 3000rpm

    Ask Lasest Price
    Brand Name : OMRON
    Model Number : R88M-G05030T
    Price : negotiable
    Payment Terms : T/T
    Supply Ability : 1000pcs per year
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    OMRON AC Servomotor With ABS INC Encoder 50W 100 VAC R88M-G05030T Without Key Without Brake 3000rpm

    OMRON AC Servomotor With ABS INC Encoder 50W 100 VAC R88M-G05030T Without Key Without Brake 3000rpm


    Quick Details:

    Model (R88M-)G05030HG10030HG20030HG40030HG75030H
    ItemUnitG05030TG10030TG20030TG40030TG75030T
    Rated output t * 1W50100200400750
    Rated torque * 1N·m0.160.320.641.32.4
    Rated rotation speedr/min3000
    Max. momentary rotation speedr/min50004500
    Max. momentary torque * 1N·m0.450.901.783.677.05
    Rated current * 1A (rms)1.11.11.62.64
    Max. momentary current * 1A (rms)3.43.44.97.912.1
    Rotor inertiakg·m2
    (GD2/4)
    2.5 × 10-65.1 × 10-61.4 × 10-52.6 × 10-58.7 × 10-5
    Applicable load inertia---30 times the rotor inertia max. *220 times the
    rotor inertia
    max. *2
    Torque constant * 1N·m/A0.140.190.410.510.64
    Power rate * 1kW/s10.420.130.362.566
    Mechanical time constantms1.561.10.710.520.45
    Electrical time constantms0.70.792.634.6
    Allowable radial load *3N6868245245392
    Allowable thrust load *3N58589898147
    WeightWithout brakekgApprox. 0.3Approx. 0.5Approx. 0.8Approx. 1.2Approx. 2.3
    With brakekgApprox. 0.5Approx. 0.7Approx. 1.3Approx. 1.7Approx. 3.1
    Radiation shield dimensions (material)100 × 80 × t10 (AI)130 × 120 × t12 (AI)170 × 160 ×
    t12 (AI)
    Applicable Servo Drives (R88D-)GT01HGT01HGT02HGT04HGT08H
    Brake
    specifi-
    cations
    Brake inertiakg·m2
    (GD2/4)
    2 × 10-72 × 10-71.8 × 10-61.8 × 10-67.5 × 10-6
    Excitation voltage *4V24 VDC ± 5%
    Power consumption
    (at 20 °C)
    W779910
    Current consumption
    (at 20 °C)
    A0.30.30.360.360.42
    Static friction torqueN·m0.29 min.0.29 min.1.27 min.1.27 min.2.45 min.
    Attraction time *5ms35 max.35 max.50 max.50 max.70 max.
    Release time *5ms20 max.20 max.15 max.15 max.20 max.
    Backlash± 1 °
    Allowable work per
    braking
    J39.239.2137137196
    Allowable total workJ4.9 × 1034.9 × 10344.1 × 10344.1 × 103147 × 103
    Allowable angular
    acceleration
    rad/s230,000 max.
    (Speed of 2,800 r/min or more must not be changed in less than 10 ms)
    Brake life---10,000,000 operations min.
    Rating---Continuous
    Insulation grade---Type F

    Similar Model:

    SpecificationsModel
    Straight shaftStraight shaft with key and tap
    Without brake100 V50 WR88M-G05030TR88M-G05030T-S2
    100 WR88M-G10030SR88M-G10030S-S2
    200 WR88M-G20030SR88M-G20030S-S2
    200 V400 WR88M-G40030SR88M-G40030S-S2
    50 WR88M-G05030TR88M-G05030T-S2
    100 WR88M-G10030TR88M-G10030T-S2
    200 WR88M-G20030TR88M-G20030T-S2
    400 WR88M-G40030TR88M-G40030T-S2
    750 WR88M-G75030TR88M-G75030T-S2
    1 kWR88M-G1K030TR88M-G1K030T-S2
    1.5 kWR88M-G1K530TR88M-G1K530T-S2
    2 kWR88M-G2K030TR88M-G2K030T-S2
    3 kWR88M-G3K030TR88M-G3K030T-S2
    4 kWR88M-G4K030TR88M-G4K030T-S2
    5 kWR88M-G5K030TR88M-G5K030T-S2
    With brake100 V50 WR88M-G05030T-BR88M-G05030T-BS2
    100 WR88M-G10030S-BR88M-G10030S-BS2
    200 WR88M-G20030S-BR88M-G20030S-BS2
    400 WR88M-G40030S-BR88M-G40030S-BS2
    200 V50 WR88M-G05030T-BR88M-G05030T-BS2
    100 WR88M-G10030T-BR88M-G10030T-BS2
    200 WR88M-G20030T-BR88M-G20030T-BS2
    400 WR88M-G40030T-BR88M-G40030T-BS2
    750 WR88M-G75030T-BR88M-G75030T-BS2
    1 kWR88M-G1K030T-BR88M-G1K030T-BS2
    1.5 kWR88M-G1K530T-BR88M-G1K530T-BS2
    2 kWR88M-G2K030T-BR88M-G2K030T-BS2
    3 kWR88M-G3K030T-BR88M-G3K030T-BS2
    4 kWR88M-G4K030T-BR88M-G4K030T-BS2
    5 kWR88M-G5K030T-BR88M-G5K030T-BS2
