Redundant Power Supply Module HONEYWELL CC-PCF901 51405047-175
CONTROL FIREWALL MODULE
C300 Controller
The C300 Controller is constructed using the Series C form factor
that employs an Input Output
Termination Assembly (IOTA) and an electronics module which mounts
and connects to the IOTA. One
C300 Controller contains all of the control functionality and the
communications functions with plug-in
modules.
The C300 Controller may operate in both non-redundant and redundant
configurations. Redundant
operation requires a second identical controller and connecting
cables, which is the typical configuration.
The C300 Controller is connected to the associated I/O hardware by
a pair of I/O Link Interface cables
The table below identifies the C300 Controller components and its
associated components.
TheC300Controller supports non-redundant and fully redundant
operation. Redundancy is built in to the controller,so that just
adding another controller and a redundancy cable; a redundant
controller pair is achieved.Note that the ‘CC’ designation on the
model number indicates the printed
C300 Controller Module
A distributed process controller and I/O gateway for the Experion
system. Module contains printed circuit assemblies, status
indicators and a display, inside in a plastic housing. Module
mounts to its Input Output Termination Assembly (IOTA). Supply
Rating: 0.311A @ 24VDC CC-PCNT01 CU-PCNT01
C300 Controller Input Output Termination Assembly (IOTA)
Provides the connection point for theC300 Controller module and all
cable terminations to the controller, (FTE, IO Link, Redundancy,
Battery and Time Source cable terminations). Provides 24Vdc power
distribution to the controller module. Supply Rating: 0.311A @
24VDC Note: The C300 Controller IOTA supports only one controller
module. CC-TCNT01 CU-TCNT01
9 Port FTE Control Firewall Module
Provides FTE distribution to in-cabinet network nodes. (C300
Controllers and Series C Modules) Supply Rating: 0.112A @ 24VDC
CC-PCF901 CU-PCF901
9 Port Control Firewall IOTA
Provides connection for eight FTE cables from in-cabinet
controllers and Series CFIMs. The 9th port provides an uplink to
the FTE supervisory network. Provides 24Vdc power distribution to
the control. Ethernet: 9 RJ-45 Connections Fiber-Optic: Model
Ca-FSMx01 FTE Single Mode Fiber Module Supply Rating: 0.30mA@24VDC
Model Ca-FMMx01 FTE Multi-Mode Fiber Module Supply Rating:
0.30mA@24VDC C-TCF901 CU-TCF901
Model Processing customized Scope Accuracy class
CC-PCF901 Yes C300 1
Power Input Output C300
60W 64 64 DCS
Brand :Honeywell
Model:Honeywell DCS CC-SDOR01
Quality:Original
Use: DCS
Custom processing: Yes
Application:Petrochemical and other fields
Brand Name: Honeywell
Condition:New and Original
Type: PLC module
Package: Factory Sealed
Warranty: 12month
Place of Origin: United States
Samples: Not Available
Delivery Time:
Shipped In 3 Days After Payment
Packing: ORIGINAL PACKING FACTORY SEALED
Delivery Port: Shenzhen
Max. Production Capacity: 200 Piece/Pieces Per Week
Export Ratio: 21% - 30%
OE Experience: No
